Slender-type Cabinets

PRODUCTS

Slender-type Cabinets

Product Description

The vertical design saves space: Slender-type Cabinets have a narrow footprint, making them suitable for laboratories with limited space.
Product Details
Specification

  • Flexible placement: They can be placed against walls or in corners without affecting the efficiency of the main laboratory workspace.
  • asy maintenance and cleaning: The compact structure reduces dust accumulation, making daily cleaning and maintenance more convenient.
  • Ventilation design reduces harmful gas accumulation: Equipped with an exhaust system to effectively remove hazardous gases, ensuring the safety of laboratory personnel.
  • Improves space utilization: Provides additional storage capacity in limited laboratory space, organizing equipment and reagents efficiently.
  • Ensures laboratory personnel safety: Proper storage of hazardous substances reduces exposure risks.








  • FM Approvals certified, comply with NFPA & OSHA regulations.
  • Heavy-duty steel construction. Lead-free epoxy powder coating finish.
  • Double wall construction with 38mm air space efficiently isolates from combustion.
  • 3-point self-latching doors with all non-spark latching.
  • Paddle handle locking latch. 1.2mm cold-rolled continuous piano hinge.
  • Adjustable zinc plated leveling feet. Dual 2” vents with caps and flame arrester placed at both side of cabinets.
  • Large warning label. Static grounding wire (UL listed).
  • 2 inch deep leak-tight containment sump.



Capacity
gallon
Ext. Dim.
W*D*H mm
Int. Dim.
W*D*H mm
No. of Shelves Door Type Order No. Approval Compliance
22 595*460*1720 512*378*1574 3 Single door/manual-close M1022Y-R FM NFPA, OSHA
Single door/self-close S1022Y-R
54 595*860*1720 512*778*1574 3 Single door/manual-close M1054Y-R FM NFPA, OSHA
Single door/self-close M1054Y-R
